Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System

I'm Online Chat Now

Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System

Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System
Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System

Large Image :  Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System

Product Details:
Place of Origin: China
Certification: CE, ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1000-39000
Packaging Details: Carton/Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 10sets/month

Electric CNC Metal Lathe Mt6 High Precision Cnc Lathe With Program Control System

Description
Model NO.: CK-32L/36L/40L/50L Automatic Grade: Automatic
Setting Mode: Table Precision: Precision
Condition: New Max.Swing Over Bed: 320
Max.Diameter Over Slide: 180 Max.Cutting Length: 500
Taper Of Spindle Bore: Mt6 Transport Package: Package
Specification: CE Trademark: G&G
Origin: China Jiangsu HS Code: 84589900
Type: Horizontal Lathe Processing Accessory: Chuck CNC Lathe
Guide Rail: With Slanting Rail 45° Tool Holder: Single-tool Holder CNC Lathe
Power Source: Electric Controlling Mode: CNC
High Light:

CNC Metal Lathe Mt6

,

Mt6 High Precision Cnc Lathe

,

Program Control System CNC Metal Lathe

CNC Center Professional CNC Lather (With Slanting Rail 45&Deg;)

Min.Order Quantity: 1 Set/Sets
Supply Ability: 200 Set/Sets per Month
Port: Qingdao/Shanghai
Payment Terms: T/T

Quick Details
Condition: New
CNC or Not: CNC
Automatic Grade: Automatic
Place of Origin: Shandong, China (Mainland)
Brand Name: Weihao
Model Number: CK32L
Certification: CE
After-sales Service Provided: No overseas service provided

Packaging & Delivery
Delivery Detail: 30-45days



Items Specifications
CK-32L/36L CK-40L CK-50L
Max.swing over bed Φ320mm /Φ360mm Φ400mm Φ500mm
Max.swing over carriage Φ180mm / Φ210mm Φ260mm Φ360mm
Max.cutting length  500mm 520mm 750mm
Rail width 284mm 320mm 381mm
Spindle nose A2-5 A2-6 A2-8
Spindle bore Φ56mm Φ62mm Φ90mm
Taper of Spindle bore MT6 MT6 or Φ70mm,1:20 Φ100mm,1:20
Chuck 6" 8" 10"
Range of spindle speed 150-4500rmp 100-3500rpm 150-3000rpm
X/Z a-xis travel 210/500mm 240/550mm 260/750mm
X/Z rapid speed 15/18m/min 15/18m/min 10/15m/min
X/Z screw 2510/3210mm 3208/4010mm 2510/4010mm
X/Z linear guide-way 25/35mm 35/45mm 30/45mm
Hydralldic turret 6 or 8 8 or 12 8 or 12
Max.section of tool 20x20mm 25x25mm 25x25mm
Stroke of tailstock sleeve 80mm 80mm 120mm
Diameter/Hole of tailstock sleeve Φ60mm/MT4 Φ75mm/MT5 Φ90mm/MT5
Main moror power 4kw/5.5kw 7.5kw 11kw or 15kw
Coolant pump power 250w 250w 250w
Overall dimensions (LxWxH) 2570x1550x1750mm 2800x1800x1800mm 3100x1880x1900mm
Packing size (LxWxH) 3000x1750x2100mm 3100x2000x2100mm 3300x2050x2150mm
Net weight 2000kg / 2200kg 2900kg 4300kg
Groos weight 2250kg / 2450kg 3300kg 4700kg

CNC Center Professional CNC Lather (with slanting rail 45°)
CNC Center Professional CNC Lather (with slanting rail 45°)

CNC Center Professional CNC Lather (with slanting rail 45°)

CNC Center Professional CNC Lather (with slanting rail 45°)
CNC Center Professional CNC Lather (with slanting rail 45°)
CNC Lathe Machine Characteristics:

CNC machine tool is the abbreviation of digital control machine tool, which is an automatic machine tool with program control system. The control system can logically process and decode the program with control code or other symbolic instructions to cause the machine to operate and machine the part.

Compared with ordinary machine tools, CNC machine tools have the following characteristics:
1. High processing precision and stable processing quality;
Multi-coordinate linkage can be performed to process parts with complex shapes;
2. When the machined parts are changed, generally only need to change the NC program, which can save production preparation time;
3. The machine tool itself has high precision and rigidity, and can choose favorable processing amount, and the productivity is high (usually 3~5 times of ordinary machine tools);
4. The degree of automation of the machine tool is high, which can reduce the labor intensity;
5. Widening high stability bed
6.Two gear spindle speed, stepless in gear
7. Wider layor board
8. Intergrated automatic lubrication system.

Application:
CNC lathes are one of the most widely used CNC machine tools. The machine is suitable to process all kinds of small and middle-sized shaft and plate workpiece, and could also turn various threads, circle arc, circle cone, inside and outside surface of revolved body.  and can be used for grooving, drilling, reaming and reaming. Holes and pupils, etc.This machine is widely used in sanitary, value, electrical appliance, instrument, automobile, motor cycle, bearing and so on.

FAQ
1. What level of service do you provide ?
--->Your inquiry will be replied within 24 hours.

2. Technology support by providing operation?training videos?
---->Professional after-sales service team.
     We can Provide Technical support online service  and Machine operation Vedio
     We can provide on-site  training and commissioning Vedio
     We can Provide Spare parts replacement and repair service
     Give reasonable offers with the best quality.

3. What is our advantages?
----> Competitive price: We can meet your budget and best-selling business very well.
      OEM Accepted: We can produce customized design.
      Good Service: We treat clients as friends and provide problem solving anytime you need.
       Good Quality: We have strict quality control system. Good reputation in the market.
       Fast & Delivery: We have big discount from forwarder (Long-term Contract).

4. Can you customize the machine for the customer?
---->Yes. We can, if you need customized services, please contact us

5. What is the MOQ?
---->We usually provide 1 set for customers to test.

6.What is your delivery time?
---->The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.

7.What is your payment method?
---->We prefer to do 100% T/T (30% T/T in advance, 70% T/T before delivery)

8.Agents Wanted:
---->We have strong partnerships in Europe, America, South America, India, Southeast Asia and South Africa. We also supply OEM service, and we are looking for agents in these areas. In the further, we want to develop SCHULER to a global brand. Wherever you are from, we are looking forward to explore new market with you.


CNC Center Professional CNC Lather (with slanting rail 45°)
CNC Center Professional CNC Lather (with slanting rail 45°)
