Product Details:
|
| Model NO.: | CQ6128 | Automatic Grade: | Manual |
|---|---|---|---|
| Setting Mode: | Table | Precision: | Precision |
| Condition: | New | Max. Travel Of Cross Slide: | 110mm |
| Max. Travel Of Top Slide: | 70mm | Max. Travel Of Tailstock Quill: | 80mm |
| Power Of Motor: | 750W | Packing Size: | 1320X650X640mm |
| Transport Package: | Package | Specification: | CE |
| Trademark: | GNG MACHINE | Origin: | China Jiangsu |
| HS Code: | 84589900 | Supply Ability: | 300/Per Month |
| Type: | Horizontal Lathe | Processing Accessory: | Chuck CNC Lathe |
| Guide Rail: | Horizontal Guide Rail | Tool Holder: | Single-tool Holder CNC Lathe |
| Power Source: | Electric | Controlling Mode: | Artificial |
| High Light: | Mini Precision CNC Metal Lathe,Wear Resisting CNC Metal Lathe,Wear Resisting Bench Lathe Machine |
||
Specifications
Precision ground and supersonic frequency hardened bed ways.
It features with high accuracy and well wear-resisting.
| CQ6128 PRECISION LATHE | |||||
| Technical spec. | C6128 | ||||
| FOBQingDao Price(USD) | |||||
| Max. swing over bed | Φ 280mm | ||||
| Max. swing over cross slide | Φ 150mm | ||||
| Distance between centers | 610mm | ||||
| Width of bed | 180mm | ||||
| Spindle bore | 26mm | ||||
| Taper of spindle bore | MT4 | ||||
| Range of spindle speeds | 125-2000rpm | ||||
| Taper of tailstock quill | MT3 | ||||
| Metric threads can be cut | 0.1-3.5mm | ||||
| Inch threads can be cut | 8-35TPI | ||||
| Range of longitudinal feeds | 0.1-0.25mm/rev | ||||
| Max. travel of cross slide | 110mm | ||||
| Max. travel of top slide | 70mm | ||||
| Max. travel of tailstock quill | 80mm | ||||
| Power of motor | 750w | ||||
| Packing size | 1320x650x640mm | ||||
| Net /Gross weight | 218/258kg | ||||
| Foot stand size | 280x390x600mm | ||||
| Foot stand net/gross weight | 52/56kg | ||||
| Standard Accessories | 1.3 jaw chuck 3. tool box and tools 2. change gears set 4. dead centers |
||||
| Optional Accessories | 1.4 jaw chuck 7. splash guard 2. face plate 8. oil tray 3. steady rest 9. foot stands 4. follow rest 10. leadscrew guard 5. live center 11. chuck guard 6. turning tools set 12. drill chuck + drill arbor |
||||
