Manual Metal Cutting Lathe Machine SN50Cx1000 Heavy Duty Metal Lathe

Description
Model NO.: SN50Cx1000/1500/2000 Automatic Grade: Manual
Setting Mode: Table Precision: Precision
Condition: New Swing Over Bed: 410mm(16" )
Swing Over Cross Slide: 224mm(8-13/16" ) Swing In Gap: 640mm(25-1/8" )
Length Of Gap: 155mm(6-1/8" ) Max Length Of Workpiece: 1000mm(40" )/1500(60" )
Transport Package: Package Specification: CE
Trademark: G&G Origin: China Jiangsu
HS Code: 84589900 Supply Ability: 300/Per Month
Type: Horizontal Lathe Processing Accessory: Chuck CNC Lathe
Guide Rail: Horizontal Guide Rail Tool Holder: Single-tool Holder CNC Lathe
Power Source: Electric Controlling Mode: Artificial
High Light:

Metal Cutting Lathe Machine SN50Cx1000

,

SN50Cx1000 Heavy Duty Metal Lathe

,

Manual Metal Cutting Lathe Machine

Precision Heavey Duty Metal Processing Lathe

Heavy Duty Metal Lathe SN50Cx1000/1500/2000

Specification:
Max. Swing Over Bed : 500mm
Max. Swing Over Carriage : 270mm
Max. Swing Over The Bed Gap : 700mm
Effective Gap Length : 357mm
Max. Length Of Workpiece :1000/1500/2000mm
Width Of Bed : 340mm

Spindle Nose : C6
Spindle Bore : φ52mm
Taper Of Spindle Bore : MT6
Range Of Spindle Speed : 25-850rpm

Etric Threads-Number/ Pitch : 29/0,5-40 Nr./mm
Whitworth Threads-Number/ Pitch :38/1-80 Nr./TPI
Modular Threads-Number/ Pitch : 26/0,25-20 Nr./mm
Diametral Pitch Threads-Number/ Number Of DP Threads:31/2-72 Nr./ Nr.
Cross Slide Working Travel : 300mm
Transverse Slide Working Travel : 500/750/1000mm
Tool Slide Working Travel : 140mm
Max. Section Of Tool : 32x32mm

Stroke Of tailstock Sleeve : 180mm
Diameter/Hole Of Tailstock Sleeve : φ70mm/MT5

Main Motor Power : 5.5KW
Coolant Pump Power : 120W

Packing Size LxWxH : 2700/3200/3700 x 1100 x 1900mm
N.W : 1735/1835/1950 Kgs
G.W : 1935/2035/2250 Kgs
