C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe

I'm Online Chat Now

C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe

C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe
C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe
C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe

Large Image :  C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe

Product Details:
Place of Origin: China
Certification: CE, ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1000-39000
Packaging Details: Carton/Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 10sets/month

C6251 CNC Metal Lathe Heavey Duty Super Rigidity Single Phase Metal Lathe

Description
Model NO.: C6251 Automatic Grade: Manual
Setting Mode: Table Precision: Precision
Condition: New Spindle Nose: D1-6
Spindle Bore: 58mm Max. Swing Diameter: 410mm
Voltage: 230V Power(W): 4000W
Transport Package: Package Specification: CE
Trademark: G&G Origin: China Jiangsu
HS Code: 845899000 Supply Ability: 300/Per Month
Type: Horizontal Lathe Processing Accessory: Chuck CNC Lathe
Guide Rail: Horizontal Guide Rail Tool Holder: Single-tool Holder CNC Lathe
Power Source: Electric Controlling Mode: Artificial
High Light:

C6251 CNC Metal Lathe

,

C6251 Single Phase Metal Lathe

,

Super Rigidity Single Phase Metal Lathe

High Precision Heavey Duty Lathe Metal Machine C6251/C6256

Min. Order Quantity: 1 Set/Sets
Supply Ability: 200 Set/Sets per Month
Port: Qingdao/Shanghai
Payment Terms: T/T

Quick Details
Condition: New
Type: Horizontal
CNC or Not: Normal
Automatic Grade: Manual
Place of Origin: Shandong, China (Mainland)
Brand Name: GNG
Model Number: C6256
Certification: CE
After-sales Service Provided: No overseas service provided

Packaging & Delivery
Delivery Detail: 30-45days



High Precision Heavey Duty Lathe Metal Machine C6251/C6256

Packaging & Delivery
Delivery Detail: 30-45days

Specifications
Precision ground and supersonic frequency hardened bed ways is designed in double wall structure,giving super rigidity.
PRECISION  METAL LATHE MACHINE
Technical spec. C6241 C6246 C6251 C6256
FOBQingDao Price(USD)
Swing over bed 410mm(16" ) 460mm(18" ) 510mm(20" ) 560mm(22" )
Swing over cross slide 220mm(8-13/16" ) 270mm(10-3/4" ) 305mm(12" ) 355mm(14" )
Swing in gap diameter 640mm(25-1/8" ) 690mm(27-1/8" ) 735mm(28-7/8" ) 785mm(30-7/8" )
Distance between centers 1000mm(40")
1500mm(60")
2500mm(80")
1000mm(40")
1500mm(60")
2500mm(80")
300mm(120")
Valid length of gap 165mm(6-1/2" ) 170mm(6-11/16" )
Width of bed 300(11-13/16") 350(13-13/16")
Spindle nose D1-6 D1-8
Spindle bore 58mm(2-1/4" ) 80mm(3-1/8" )
Taper of spindle bore NO. 6 Morse NO. 7 Morse
Range of sppindle speed 12changes 25-2000r/min
Compound rest travel 128mm(5" ) 130mm(5-1/8" )
Cross slide travel 285mm(11-1/4" ) 316mm(12-7/16" )
Max section of tool 20mmx20mm(1x1" )
Lead screw thread  6mm or 4T.P.I
Longitudinal feeds range 42kinds 0.031-1.7mm/rev
(0.0011" -0.0633" /rev)
32kinds 0.059-1.646mm/rev
(0.0022" -0.0612" /rev)
Cross feeds range 42kinds 0.014-0.784mm/rev
(0.00033" -0.01837" /rev)
42kinds 0.020-0.573mm/rev
(0.00048" -0.01354" /rev)
Threads Metric pitches 41kinds 0.1~14mm 47kinds 0.2~14mm
Threads imperial pitches 60kinds 2~112 T. P. I
Threads diametral pitches 50kinds,4~112 DP
Threads module pitches 34kinds,0.1~7 MP
Quill diameter 60mm(2-5/16") 75mm(2-15/16")
Quill travel 130mm(5") 180mm(7-1/16")
Quill taper No.4 Morse No.5 Morse
Main motor power 5.5KW(7.5HP) 3PH 7.5KW(10HP) 3PH
Coolant pump power 0.1KW (1/8HP) 3PH
Overall dimension L x W x H 220x108x134cm
275x108x134cm
325x108x134cm
220x108x137cm
275x108x137cm
325x108x137cm
239x115x143cm
284x115x143cm
334x115x143cm
434x115x143cm
239x115x146cm
284x115x146cm
334x115x146cm
434x115x146cm
Packing size L x W x H 225x112x162cm
280x112x162cm
330x112x162cm
225x112x162cm
280x112x156cm
330x112x156cm
245x119x174cm
290x119x174cm
340x119x174cm
440x119x174cm
245x119x174cm
290x119x174cm
340x119x174cm
440x119x174cm
Net weight 1580 kgs
1745 kgs
1900 kgs
1645 kgs
1810 kgs
1965 kgs
2070 kgs
2160 kgs
2435 kgs
2805 kgs
2195 kgs
2285 kgs
2560 kgs
2930 kgs
Gross weight 1844 kgs
2049 kgs
2229 kgs
1910 kgs
2115 kgs
2295 kgs
2460 kgs
2550 kgs
2840 kgs
3270 kgs
2600 kgs
2690 kgs
2980 kgs
3410 kgs
Standard Accessories 1.Three jaw chuck
2. Thread chasing dial
3.Tool box & tool 1 set
Special Accessories 1. Coolant system
2.Brake
3.Driving plate
4.Living center
5.Taper turning attachment
6.Drill chuck
7.Stopper
8.QCTP
9.DRO
10.Chuck cover
11.Leadscrew cover
12.Tool post cover
Lathe Features Apron box construction design patent with rapid movement.
Automatic lubrication system.
φ105mm spindle bore.
High Precision Heavey Duty Lathe Metal Machine C6251/C6256
High Precision Heavey Duty Lathe Metal Machine C6251/C6256

High Precision Heavey Duty Lathe Metal Machine C6251/C6256
High Precision Heavey Duty Lathe Metal Machine C6251/C6256
