Product Details:
Place of Origin: China
Certification: CE, ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000-50500
Packaging Details: Carton/Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 10sets/month

Desktop Structure Column Moving Surface Grinder With Program Control

Description
Model NO.: MY1230 Automatic Grade: Automatic
Precision: Precision Condition: New
Max.Workpiece To Be Ground (Lxwxh)(Mm): 700X320 Maximum Travel Of Table (Lxw)(Mm): 760X320
Table Maximum Cutting Area (Lxw)(Mm): 760X320 Number Of T-Slot T(Mm): 1X14
Spindle Speeds (50Hz)(R/M): 1440 Transport Package: Carton Or Wood Case
Specification: CE ISO Trademark: GNG MACHINE
Origin: China HS Code: 84571010
Type: Hydraulic Automatic Precision Grinder Object: Gear
Structure: Desktop Milling Cutter Type: Vertical Milling Cutter
Milling Cutter Structure: Overall Welding Tooth Controlling Mode: Program Control
High Light:

Desktop Structure Column Moving Surface Grinder

,

Desktop Structure Column Surface Grinder

,

Program Control Column Moving Surface Grinder

Hydraulic Automatic Precision Grinder Milling Machine

Company Info.

Basic Info.

Model NO.
MY1230
Automatic Grade
Automatic
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Max.Workpiece to Be Ground (Lxwxh)(Mm)
700X320
Maximum Travel of Table (Lxw)(Mm)
760X320
Table Maximum Cutting Area (Lxw)(Mm)
760X320
Number of T-Slot T(Mm)
1X14
Spindle Speeds (50Hz)(R/M)
1440
Transport Package
Carton or Wood Case
Specification
CE ISO
Trademark
GNG MACHINE
Origin
China
HS Code
84571010
Production Capacity
1000 Sets/Month

Product Description

Hydraulic Automatic Precision Grinder Milling Machine

Characteristics of machine tools:
       The machine is reasonable in structure, good rigidity, beautiful appearance, convenient operation.
       Using precision plastic guide surface and precision scraping, grinding imported hydraulic transmission, drive by synchronous.
       The main mechanical valve is a special valve grinder, is divided into two parts, the mechanical commutation control, throttle control. Throttle control part and unloading function, can realize the station start and stop.
       Grinding can be all kinds of plane and complex shaped surface, suitable for motor without grinding the feed, according to user needs with a permanent magnet sucker or electromagnetic sucker.
Model       MY1230
Bench              Max.workpiece  to  be Ground (L×W×H)                         (×) mm 700×320
Maximum travel of table (L × W)                         (×) mm 760×320
 Table maximum cutting area (L × W)                      (×) mm 760×320
Number  of  T -Slot  T (×) mm 1×14
The grinding head        Distance  From  Table Surface  To  Spindle  Center                                  m 540
Wheel  Size(dia×width×bore)                                    (WA46K5V) (××) mm ø335×30×ø127
Spindle speeds     (50HZ) r/m 1440
The amount of feed                        Table longitudinal (left and right) speed (stepless)                ()() /min 5    25
Table horizontal (before and after) the amount of feed                      () Continuous (variable speed)() mm/min 150
Intermittent (stepless)      () m/ 0      5
The handwheel rotates mm 4
Hand wheel each grid mm 0.02
Vertical (up and down) feed wheel feed                       () The handwheel rotates mm 2
Hand wheel each grid mm 0.01
Motor power Spindle motor       kw 4
Cooling motor       kw 40
Reversing feeder      Hydraulic motor        kw 1.5
Working pressure      mpa 3
Fuel tank capacity  L 80
The maximum flow      L/min 18
Working precision      The machined surface of the base of parallelism                              mm 300/0.004
Surface  Roughness     μm Ra0.32
Weight of machine Net      T 2.1
Cross   T 2.35
Machine  Size (L×W×H)      (××) mm 1990×1700×1990


Hydraulic Automatic Precision Grinder Milling Machine
Hydraulic Automatic Precision Grinder Milling Machine
Hydraulic Automatic Precision Grinder Milling Machine
Hydraulic Automatic Precision Grinder Milling Machine
Hydraulic Automatic Precision Grinder Milling Machine
