150W Surface Grinding Machine No Impact Universal Cylindrical Grinder

I'm Online Chat Now

150W Surface Grinding Machine No Impact Universal Cylindrical Grinder

150W Surface Grinding Machine No Impact Universal Cylindrical Grinder
150W Surface Grinding Machine No Impact Universal Cylindrical Grinder 150W Surface Grinding Machine No Impact Universal Cylindrical Grinder 150W Surface Grinding Machine No Impact Universal Cylindrical Grinder 150W Surface Grinding Machine No Impact Universal Cylindrical Grinder 150W Surface Grinding Machine No Impact Universal Cylindrical Grinder 150W Surface Grinding Machine No Impact Universal Cylindrical Grinder

Large Image :  150W Surface Grinding Machine No Impact Universal Cylindrical Grinder

Product Details:
Place of Origin: China
Certification: CE, ISO 9001
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000-50500
Packaging Details: Carton/Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 10sets/month

150W Surface Grinding Machine No Impact Universal Cylindrical Grinder

Description
Model NO.: MD618 Precision: Precision
Distance From Table Surface To Spind: 335mm Net Weight: 750kg
Gross Weight: 800kg The Total Input Power: 150W
Number Of T -Slot T (×): 1×12mm Transport Package: Carton Or Wood Case
Specification: CE ISO Trademark: G&G
Origin: China HS Code: 84571010
Supply Ability: 1000 Sets/Month Type: Surface Grinding Machine
Processing Object: Gear Abrasives: Grinding Wheel
Controlling Mode: Artificial Automatic Grade: Automatic
Cylindrical Grinder Type: Universal Cylindrical Grinder
High Light:

150W Surface Grinding Machine

,

150W Universal Cylindrical Grinder

Professional Automatic Precision Surface Milling Grinder Machine

Company Info.

Basic Info.

Model NO.
MD618
Precision
Precision
Certification
CE, ISO 9001
Distance From Table Surface to Spind
335mm
Net Weight
750kg
Gross Weight
800kg
The Total Input Power
150W
Number of T -Slot T (×)
1×12mm
Transport Package
Carton or Wood Case
Specification
CE ISO
Trademark
G&G
Origin
China
HS Code
84571010
Production Capacity
1000 Sets/Month

Product Description


Characteristics of machine tools:
Based on manual surface grinder, it covert the longitudinal and vertical machine to fully automatic The bidirectional friction electronic clutch, simple and reliable structure, clutch reversing process has no impact, no noise, safe commutation 5000000 times; the electric control part with electronic switching frequency switching, The service life 10 times longer than the relay control, simple operation, sensitive, infinitely variable; large output torque, low noise, Safe and reliable.  Power supply use a number of mechanical and electrical protection function which is safe voltage, Energy saving, power saving, power consumption per class (calculated according to 8 hours) is only 0.6.When the manual grinding is working,Before and after the workbench's movement, in and out, around the reversing are automatic operation, greatly improving the production's efficiency and the surface finish, suitable scope that from the original single, small  batch to mass batch.
Model         MD618
Bench     Max.workpiece  to  be Ground (L×W×H)   (×) mm 460×180
Maximum travel of table (L × W)         (×) mm 500×190
Table maximum cutting area (L × W)     (×) mm 500×190
Number  of  T -Slot  T (×) mm 1×12
The grinding head        Distance  From  Table Surface  To  Spindle  Center                                                             mm 335
Wheel  Size(dia×width×bore)                                                         (WA46K5V) (××) mm ø200×20×31.75
Spindle speeds     (50HZ) r/m 2850
The amount of feed    Table longitudinal (left and right) speed (stepless)                                          ()() /min 3--23
Table horizontal (before and after) the amount of feed                      () Continuous (variable speed)                      () m/min 150
Intermittent (stepless)                   () m/ 0-5
The handwheel rotates    mm 2.5
Hand wheel each grid      mm 0.02
Vertical (up and down) feed wheel feed                                        () The handwheel rotates    mm 1.25
Hand wheel each grid     mm 0.01
Reversing feeder          The total input power    W 150
X- feeder output speed.   X- /min 0--225
X- feeder size   X- m 280×130×120
Y- feeder output speed.   Y- /min 0--120
Y- feeder size M    Y- m 280×130×120
Motor power            Spindle motor  kw 1.1
Cooling motor  kw 0.4
Working precision                 The machined surface of the base of parallelism                          m 300/0.005
Surface  Roughness     μm Ra0.32
Weight of machine                         Net      kg 750
Cross   kg 800
Packing  Size (L×W×H)      (××) m 1060×1170×1870

Professional Automatic Precision Surface Milling Grinder MachineProfessional Automatic Precision Surface Milling Grinder MachineProfessional Automatic Precision Surface Milling Grinder Machine
Professional Automatic Precision Surface Milling Grinder Machine
Professional Automatic Precision Surface Milling Grinder Machine




Professional Automatic Precision Surface Milling Grinder Machine

Professional Automatic Precision Surface Milling Grinder Machine
