Product Details:
|
| Model NO.: | XJ9512 | Precision: | Precision |
|---|---|---|---|
| Condition: | New | Cross Travel: | 100/130mm |
| Spindle Stroke: | 180mm | Drilling Capacity: | 16mm |
| Milling Capacity: | 30mm | Motor Power: | 550W |
| Transport Package: | Package | Specification: | CE |
| Trademark: | Can Use Customer Brand | Origin: | China |
| HS Code: | 845959000 | Supply Ability: | 300/Per Month |
| Structure: | Vertical Drilling Machine | Layout: | Vertical |
| Controlling Mode: | Artificial | Number Of Shaft: | 3 |
| Hole Diameter: | <50mm | Automatic Grade: | Semiautomatic |
| High Light: | Cnc Drilling Milling Machine 30mm,Drilling Milling Machine 30mm,Semiautomatic Cnc Drilling Milling Machine |
||
| XJ9512 MINI DRILLING & MILLING MACHINE | ||||
| Technical spec. | XJ9512 | |||
| FOBQingDao Price(USD) | ||||
| Drilling capacity | 16mm | |||
| Max face millcapacity | 30mm | |||
| Max end mill capacity | 13mm | |||
| Spindle stroke | 180mm | |||
| Longitudinal travel | 250/300mm | |||
| Cross travel | 100/130mm | |||
| Spindle rotary angle | -45~+45 | |||
| Working table size | 410/460x112mm | |||
| Motor power | 550W | |||
| Max distance spindle to table | 220mm | |||
| Spindle taper | MT3 | |||
| Spindle speed | 50-2500RPM | |||
| Net weight/Gross weight | 62/80kg | |||
| Packing size | 570x510x740mm 640x565x720mm | |||
| Product featues | *Variable speed *Spindle micrp feed *DC motor *Positive spindle lock *Imported speed control unit *Adjusrable gibs on table *Milling, drilling. boring, reaming. *Accurate position, strong rigidity, strong cutting power *Head swivels ± 45° of perpendicular |
|||
Contact Person: Mrs. Grace Li
Tel: 13853295953
