Product Details:
|
| Model NO.: | JYP280V | Automatic Grade: | Manual |
|---|---|---|---|
| Setting Mode: | Table | Precision: | Precision |
| Condition: | New | Voltage: | 220V |
| Power(W): | 750 | Dimension(L*W*H): | 140X71X68cm |
| Weight: | 190kgs | Spindle Bore: | 26mm |
| Transport Package: | Package | Specification: | CE |
| Trademark: | G&G | Origin: | China Anhui |
| HS Code: | 84589900 | Supply Ability: | 300/Per Month |
| Type: | Horizontal Lathe | Processing Accessory: | Chuck CNC Lathe |
| Guide Rail: | Horizontal Guide Rail | Tool Holder: | Single-tool Holder CNC Lathe |
| Power Source: | Electric | Controlling Mode: | Artificial |
| High Light: | 220V Milling Drilling Machine,220V Mill Drill Machine,Manual Mill Drill Machine |
||
| Distance between centers | 700mm |
Swing over bed |
280mm |
Swing over cross slide |
165mm |
Width of bed |
180mm |
Taper of spindle bore |
MT4 |
Spindle bore |
26mm |
Number of spindle speeds |
6/variable speed |
Range of spindle speeds |
125-2000/50-2000rpm |
Range of longitudinal feeds |
0.07 -0.20mm /r |
Range of inch threads |
8-56T. P. I |
Range of metric threads |
0.4 -3.5mm |
Top slide travel |
80mm |
Cross slide travel |
140mm |
Tailstock quill travel |
80mm |
Taper of tailstock quill |
MT2 |
Motor |
0.75/1.1KW |
Packing size |
1400 × 7060 × 680mm |
Net weight |
190kg |
| Name | QTY |
Splash guard |
1pc |
Chip tray |
1pc |
Toolbox & tools |
1pc |
