Product Details:
|
You can get our good service after buy from us.
Specifications
| US dollar unite Price | USD5075.00(20QP/4 pcs;40HQ/10 pcs) | USD7072.00(20QP/4 pcs;40HQ/10 pcs) |
| Model | CPD20 | CPD20PLUS |
| Rated Load | 2.0 T | 2.0 T |
| Gantry | 2 | 2 |
| Lifting/lifting height | 3m | 3m |
| Drive the lifting motor | 4kw(Brushless asynchronous AC motor) | 5kw(Brushless asynchronous AC motor) |
| Walking oil pump motor | 5kw | 5kw |
| rated voltage | 60V | 60V |
| Battery configuration | 150Ah/5pcs(Lead acid battery) | 160Ah(lithium battery) |
| Steering method | Hydraulic power assist | Hydraulic power assist |
| Tire Size | First 6.5-10; Rear 5.00-8 solid tires | First 6.5-10; Rear 5.00-8 solid tires |
| Charger | Smart charger | Smart charger |
| Charging time | Adjustable, can be fully charged in up to 3 hours, automatically shuts off when fully charged | 4h |
| Usage time | 3-4h(Continuous operation in fully charged state) | 4-6h(Continuous operation in fully charged state) |
| FORK LENGTH | 1220mm | 1220mm |
| Weight type | Steel sand cement | Cast steel integrated molding |
| Whole machine weight | 2850kg | 2950kg |
| Vehicle dimensions: L*W * H | 2350*1200*2200(Excluding forks) | 2200*1200*2100(Excluding forks) |
| Braking method | Oil brake | Oil brake |
| Idle driving speed | 14km/h | 15km/h |
| Full load driving speed | 13km/h | 13.5km/h |
| No load lifting speed | 280mm/s | 350mm/s |
| Full load lifting speed | 180mm/s | 250mm/s |
| minimum turning radius | 2700mm | 2700mm |
| Front wheelbase | 1025mm | 1035mm |
| Rear wheelbase | 925mm | 950mm |
