Product Details:
|
| Model | CPD15 |
| Rated Load | 1.5 T |
| Gantry | 2 |
| Lifting/lifting height | 3m |
| Drive the lifting motor | 4kw(Brushless asynchronous AC motor) |
| Walking oil pump motor | 3kw |
| rated voltage | 60V |
| Battery configuration | 150Ah/5pcs(Lead acid battery) |
| Steering method | Hydraulic power assist |
| Tire Size | First 6.5-10; Rear 5.0-8 solid tires |
| Charger | Smart charger |
| Charging time | Adjustable, can be fully charged in up to 3 hours, automatically shuts off when fully charged |
| Usage time | 3-4h(Continuous operation in fully charged state) |
| FORK LENGTH | 1220mm |
| Weight type | Steel sand cement |
| Whole machine weight | 2850kg |
| Vehicle dimensions: L*W * H | 2350*1200*2200(Excluding forks) |
| Braking method | Oil brake |
| Idle driving speed | 14km/h |
| Full load driving speed | 13km/h |
| No load lifting speed | 280mm/s |
| Full load lifting speed | 180mm/s |
| minimum turning radius | 2700mm |
| Front wheelbase | 1025mm |
| Rear wheelbase | 925mm |
