Product Details:
|
Min. Order Quantity: 20 Set/Sets
Supply Ability: 500 Set/Sets per Month
Port: Qingdao
Payment Terms: T/T
Condition: New
Place of Origin: Shandong, China (Mainland)
Brand Name: Weihao
After-sales Service Provided: No overseas service provided
Delivery Detail: 30-45days
Specifications
| Item | Specifications | |
| General Machine Performance | Model No. | SZ150 |
| Machine Size (L*W*H) | 6500*1850*2700mm | |
| Overall Weight | 5000kg | |
| Wheel Base | 2240mm | |
| Wheel Tread | 1480mm | |
| Min. Turning Radius | 4000mm | |
| Min. Ground Clearance | 250mm | |
| Max. Driving Speed | 30km/h | |
| Max. Climbing Capacity | 30° | |
| Engine Performance | Standard Engine | Kolher 1903(EPA4) |
| Engine Type | 4 Cylinder/Direct injection | |
| Rated Power | 41kw | |
| Rated Speed | 2200R/min | |
| Fuel Tank Capacity | 63L | |
| Loading Performance | Loading Bucket Capacity | 0.8m³ |
| Rated Loading | 1500kg | |
| Bucket Width | 1800mm | |
| Max. Unloading Height | 3200mm | |
| Max. Unloading Distance | 800mm | |
| Max. Lifting Height | 4300mm | |
| Breakout Lifting Force(KN) | 42Kn | |
| Shovel Action Time | 6.5s | |
| Digging Performance | Backhoe Bucket Capacity | 0.1m³ |
| Bucket Width | 55mm | |
| Max. Digging Depth | 2000mm | |
| Max. Digging Height | 4300mm | |
| Max. Digging Radius | 3700mm | |
| Max. Unloading Height | 3100mm | |
| Bucket Slewing Angle | 280° | |
| Bucket Digging Force | 28Kn | |
| Transmission System | Driving Type | 4*4 Four-Wheel Drive |
| Gearbox | Power Shift | |
| Gear Shift | Front 2/Rear 2 | |
| Torque Converter | 265, High and Low Speed | |
| Steering System | Steering Type | Articulated Full Hydraulic Steering |
| Steering Angle | ±33° | |
| Axles & Tyres | Axle Type | Wheel Bridge |
| Standard Tyre(Front/Rear) | 20.5-16 | |
| Tyre Pressure(Front/Rear) | 250-300Kpa | |
| Brake System | Traveling Brake | Gas cap oil power braking system |
| Parking Brake | Air Brake | |
| Braking Distance | 3100mm | |
| Hydraulic System | Variable Speed Type | Hydraulic Shift |
| System Working Pressure | 28Mpa | |
| Hydraulic Fuel Tank Capacity | 63L |
