Product Details:
|
Specifications
| Overall Performance/Models | SZT150 | SZT200 | |
| Engine Performance | Engine Model | Kolher1903 | Kolher2504 |
| Power(Kw) | 41KW | 55KW | |
| Emission | EPA&Euro5 | EPA&Euro5 | |
| Number of Cylinder | 4 | 4 | |
| General Machine Performance | Operating Weight | 3500kg | 5000kg |
| Machine Size L×W×H | 5460*1760*2750mm | 7200*2200*3200mm | |
| Wheel Base | 2200mm | 2680mm | |
| Wheel Tread | 1385mm | 1720mm | |
| Tire Size | 23.5/70-16 | 16/70-20 | |
| Bucket Performance | Rated Load(kgs) | 1500kg | 2000kg |
| Bucket Capacity Range | 0.6-0.8m³ | 1.2m³ | |
| Standard Bucket Capacity | 0.6m³ | 1.2m³ | |
| Bucket Width | 1800mm | 2400mm | |
| Dumping Height | 3500mm | 3800mm | |
| Dumping Reach | 700mm | 1050mm | |
| Max. Raising Height | 4300mm | 4300mm | |
| Braking System | Service | oil drum brake on 4 wheel | oil drum brake on 4 wheel |
| Parking Brake | Hand brake | Hand brake | |
| Transmission Performance | Transmission Type | Automatic | Automatic |
| Axle | AWD, | Middle wheel edge | |
| Gear Shift | H/L,F/R | H/L,F/R | |
| Control Lever | 1 | 1 | |
| Control Type | Joystick | Joystick | |
| Lifting Time | 5s | 5s | |
| Lowering Time | 4s | 4s | |
