180mm Thickness Planer Machine Double Sided Commercial Wood Planer

I'm Online Chat Now

180mm Thickness Planer Machine Double Sided Commercial Wood Planer

180mm Thickness Planer Machine Double Sided Commercial Wood Planer
180mm Thickness Planer Machine Double Sided Commercial Wood Planer
180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer 180mm Thickness Planer Machine Double Sided Commercial Wood Planer

Large Image :  180mm Thickness Planer Machine Double Sided Commercial Wood Planer

Product Details:
Place of Origin: China
Certification: CE, ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD 600-1570
Packaging Details: Carton/Wooden case
Delivery Time: 30-45days
Payment Terms: T/T
Supply Ability: 100sets/month

180mm Thickness Planer Machine Double Sided Commercial Wood Planer

Description
Model NO.: MB104E Cutter Shaft: 4
Spindle Speed: <5000rpm Process Type: Light Processing
Max. Planning Width: 410mm Planning Thickness: 8-180mm
Min. Planning Length: >= 200mm Max. Planning Depth: ≤ 4mm
Auto Feeding Speed: 7, 10m/Min Transport Package: Package
Specification: CE Trademark: G&G
Origin: China Shandong HS Code: 846592000
Type: Double-sided Pressure Planer Working Depth: 100-200mm
Working Width: 500-700mm Drivetrain: Feed Drivetrain
Enter Method: Pushing Motor Power: 5-10Kw
High Light:

180mm Thickness Planer Machine

,

180mm Commercial Wood Planer

,

Double Sided Thickness Planer Machine

Surface Segmented One Side Woodworking Planer

Company Info.

Basic Info.

Model NO.
MB104E
Cutter Shaft
4
Spindle Speed
<5000rpm
Process Type
Light Processing
Certification
CE, ISO
Max. Planning Width
410mm
Planning Thickness
8-180mm
Min. Planning Length
≥ 200mm
Max. Planning Depth
≤ 4mm
Auto Feeding Speed
7, 10m/Min
Transport Package
Package
Specification
CE
Trademark
G&G
Origin
China Shandong
HS Code
846592000
Production Capacity
300/Month

Product Description

Min. Order Quantity: 1 Set/Sets
Supply Ability: 100 Set/Sets per Month
Port: Qingdao
Payment Terms: T/T
Quick Details
Condition: New
Type: Bench Planer
Place of Origin: Shandong, China (Mainland)
Brand Name: GNG
Model Number: MB104E-1
Voltage: 380v
Power(W): 4000W
Dimension(L*W*H): 785x780x1190mm
Weight: 330kgs
Certification: CE
Warranty: 1year
After-sales Service Provided: No overseas service provided
Packaging & Delivery
Packaging Details: Packed in plywood case
Delivery Detail: 30-45days
Specifications
Universal cylindrical grinder. This machine is suitable for grinding external and internal cylinder and cone, and end face
Specifications
Max planing width: 410mm
Max planing amount: 4mm
Spindle speed: 6300-6450rpm
Pressing thicnkess: 8-200mm

Model

MB104E-1

MB105E-1

MB106E-1

Max. Planning Width

410mm

510mm

610mm

Planning Thickness

8-180mm

8-180mm

8-180mm

Min. Planning length

≥ 200mm

≥ 200mm

≥ 200mm

Max. Planning Depth

≤ 4mm

≤ 4mm

≤ 4mm

Auto Feeding Speed

7, 10m/min

7, 10m/min

7, 10m/min

Spindle Speed

5350-5500r/min

5350-5500r/min

4900-5100r/min

Motor Power

380v * 4kw

380v * 4kw

380v * 5.5kw

Spindle Cutting Dia

Φ 75mm

Φ 75mm

Φ 75mm

Overall Dimensions

785 * 780 * 1110mm

785 * 880 * 1110mm

790 * 980 * 1130mm

Net Weight

330kg

370kg

390kg
Surface Segmented One Side Woodworking Planer
Woodworking single side segment planer is the model can plane the segment timber,  it is developed from the traditional wood press planer.
 SINGLE SIDE PRESS PLANER FEATURE
1, More detail design to enhance product performance.
2, The body is with heavy-duty steel and with special heat treatment process,  better stability  and lower noise.
3,The strict and elaborate assembly process to ensure each equipment requirement gets to its standard indicato
We provide more models of woodworking thicknesser planers,The workbench can be lifted by manual or electric. The double sides thicknesser planers are best sales, high speed feeding thicknesser planer, heavy duty thciknesser planer.
IF ANY QUESTIONS, PLS FEEL FREE TO CONTACT WITH ME.
Surface Segmented One Side Woodworking Planer
Surface Segmented One Side Woodworking Planer
Surface Segmented One Side Woodworking Planer
Surface Segmented One Side Woodworking Planer
Surface Segmented One Side Woodworking Planer
